Quick Die Change Solutions
by Pacesetter Systems

"We Manufacture the Worlds Strongest Quick Die Change Systems"


A versatile clamp for general die clamping applications.  High reliability, large grip range and safety locks make this clamp an excellent choice.  Available in three sizes with clamping forces up to 15,000 lbs.

Model
No.

Clamping Force
@ 6,000 PSI

Width

Height

Grip Range

Length

210

4,000 lbs.

2.00

3.34

.75 - 1.75

6.40

220

10,000 lbs.

2.50

5.00

.75 - 2.25

8.84

230

15,000 lbs.

3.00

6.10

1.00 - 3.00

11.14


View a demonstration!
Play Video

A low profile clamp for applications requiring high clamping force and a minimum clamp height.  Available in three sizes with clamping forces up to 20,000 lbs.

Model
No.

Clamping Force
@ 6,000 PSI

Width

Height

Grip Range

Length

351

5,000 lbs.

2.00

2.27

.75 - 1.25

4.40

352

10,000 lbs.

3.00

2.27

.75 - 1.25

4.40

354

20,000 lbs.

4.79

2.87

1.00 - 1.50

5.60

A low profile clamp for applications requiring extremely high clamping force and allow clamps to be mounted in a fixed position.  Grip height is adjustable from .88 to 1.25 max.  Total height of clamp is 3.25 in.  Clamping force is 40,000 lbs.

Model 360

View a slide-show!
Play Video

A high force clamp for use with pocketed or slotted dies.  High reliability, large grip range with optional safety locks and mounting types make this clamp an excellent choice.  Available in three models with clamping forces up to 22,000 lbs.

Model
No.

Clamping Force
@ 6,000 PSI

Cylinder Width

Cylinder
Height

Clamp
Stroke

Mechanical
Lock

240

9,000 lbs.

2.00

2.62

.25

Standard

241

9,000 lbs.

2.00

2.00

.25

N/A

245

9,000 lbs.

2.00

2.85 / 3.47

.25

Option

260

12,000 lbs

2.50

2.73

.31

Standard

261

12,000 lbs.

2.50

2.06

.31

N/A

265

12,000 lbs.

2.50

2.96 / 3.63

.31

Option

280

22,000 lbs.

3.00

3.81

.38

Standard

281

22,000 lbs.

3.00

2.88

.38

N/A

285

22,000 lbs.

3.00

4.04 / 4.97

.38

Option
